Manufactured: 2007 - 2008
Serial Number: 3409-000001 - 3409-006150
Location of Stove Controls |
Pilot Igniter: The pilot Igniter is used only to start the pilot. When pressed, it sends an electrical charge to the pilot assembly. This creates a blue spark directly next to the pilot, igniting the pilot flame. On / Off Switch: This control is used to turn the fireplace burners on and off. Gas Control Knob: This knob is used to control gas to the fireplace and for starting the pilot. There are three positions, on, off, and pilot. The pointer to the left of the knob indicates the position this knob is in. Flame Adjust Knob: This knob controls the flame height from low to high. The pointer above the knob points to the position this knob is in. Comfort Control: This lever turns the rear burner on and off. note: this is not a shut off valve. Optional Blower Control: This knob controls the speed of the optional internal convection blower that pushes heated air into the room. Optional Accent Light: This knob controls the optional accent lights located behind the logs. |
Stove Wiring |
Blower wiring |
|
Travis Lopi Avalon Fireplace Xtrordinair 564 SS Fireplace Parts List
