Figure 1

Location of Stove Controls

Blower Knob: This Knob controls the speed of the internal convection blower that pushes the heated air into the room.
On / Off Switch: This control is used to turn the heater on and off.
Pilot Igniter: The pilot igniter is used only to start the pilot. When pressed, it sends an electrical charge to the pilot assembly. This creates a blue spark directly next to the pilot, igniting the pilot flame.
Gas Control Knob: This knob is used to control gas to the heater and for starting the pilot. There are three positions, on, off, and pilot. The pointer directly below the knob indicates the position this knob is in.
Flame Adjust Knob: This Knob controls the flame height from low to high. The pointer to the upper left of the knob points to the position this knob is in.

Normal Stove Operating Sounds

Stove Wiring
