Jotul Stoves 507 and 507UL



The Jotul 507 was manufactured from 1972-1986. A small efficient coal stove, which can also be used to burn wood. This model is vented from the back.


 Dimensions:
Height to lower edge of smoke outlet: 29.7"
Smoke outlet diameter: 4.92" (stove provided with increaser to 6".)
Required flue pipe and chimney diameter: 6"
Height: 36.4"
Length: 12.6"
Width: 13.6"
Firebox lining: firebrick, lower: cast iron, upper
Heating capacity: 3,000 - 5,500 ft.
Weight: 231 lbs.



jotul stove parts

Jotul Model 507 Parts List


Articles

Wood Stove Maintenance
How to Properly Cure and Install Cast Iron Woodstove Replacement Parts
Benefits of a Wood Stove
REF#
SKU
Name
Price
Qty
9
150602
Jotul Grate Support 11 3/8" x 11 5/8"
Each
$216.00
add to cart
11
100628
Jotul Front Grate Support 8 1/4" x 6 1/2"
Each
$85.00
add to cart
12
100629
Jotul Front Grate 6 1/2" x 5 1/8"
Each
$150.00
add to cart
13
100630
Jotul Stove Baffle 10 1/2" x 9 1/4"
Each
$188.34
add to cart
14
100631
Jotul Stove Side Liner
Each
$150.68
add to cart
15
100632
Jotul Back Burn plate
Each
$123.34
add to cart
19
100493
Jotul Pinion 1 3/4" x 1 1/2"
Each
$75.00
add to cart
20
100633
Jotul Grate 7 1/4"
Each
$160.00
add to cart
21
150105
Jotul Ash Pan
Each
$38.33
add to cart
25
120013
Jotul Door Latch
Each
$21.54
add to cart
26
101085
Jotul Cast Iron Door Handle
Each
$26.86
add to cart
28
120015
Jotul Bakelite Knob
Each
$10.00
add to cart
43
05-124817
Jotul Pipe Adapter
Each
$89.12
add to cart
55
9993
Jotul Cheese Head Bolt
Each
$5.85
add to cart
58
9931
Jotul M8 Hex Nut
Each
$1.88
add to cart
