PSG Stove Mini Caddy




Type of fuelWood
Maximum input capacity75.000 BTU (21,6 kW)
Maximum output capacity63,750 BTU (18,7 kW)
Average output capacity41,440 BTU (12,2 kW)
Maximum output - EPA test wood25,500 BTU (7,5 kW)
Blower1/4 HP Direct-drive (4 speeds)
Loading capacityUp to 40 pounds (18 kg)
Efficiency84% (LHV)
78 % (HHV)
ColorBlack
Exterior dimensionsFurnace (without the blower assembly):
23 3/4"W
29 1/8"D
45 5/8"H
Flue spigot diameter6"
Recommended exhaust pipe diameter6"
Type of chimney2100°F (1150°C)
Recommended chimney diameter6"
Firebox dimensions14"W x 19 3/8"D x 12"H
Maximum log length18 3/8"
Door opening dimensions13 1/2"W x 9 5/8"H
Type of doorGlass with cast iron frame
Hot air plenum dimensions12" x 12" *see options
Cold air plenum dimensions22 3/8"W x 13 5/8"D *see options
Ash drawer dimensions11 3/4"W x 12"D x 2 5/8"H
Number of filters1
Filters dimensions15"W x 20"D x 1"H
Minimum clearances (Front)48"
Minimum clearances (Back)24" recommended for servicing
Minimum clearances (Sides)24" recommended for servicing
Minimum clearances (Ducts)3" for the first six feet and 1" thereafter
WeightFurnace:
416 lbs (189 kg)
WarrantyLimited lifetime warranty
Test standard - safetyCan CSA B366.1-M91, CSA C22.2 No. 236, UL 1995, UL391 3e Ed. rev. 1999
Test standard - emissionsE.P.A.



PSG Mini Caddy Parts List

REF#
SKU
Name
Price
Qty
1
AC07867
Each
$8.75
add to cart
4
AC09185A
Each
$33.34
add to cart
5
SE51352
Each
$140.00
add to cart
6
AC06400
Each
$15.07
add to cart
8
PL51349
Each
$15.00
add to cart
9
OA11400
Each
$17.95
add to cart
15, 29
AC06900
Each
$10.67
add to cart
28
30168
Each
$2.40
add to cart
38
51000
Each
$160.00
add to cart
39
PA08520
Each
$630.00
add to cart
45
SE51375
Each
$495.00
add to cart
46
51009
Each
$280.00
add to cart
48
30335
Each
$2.00
add to cart
51
PL51292
Each
$45.00
add to cart
55
29020
Pack of 6
$66.15
add to cart
58
24089
Each
$45.00
add to cart
60
PL51326
Each
$60.00
add to cart
62
21212
Each
$70.31
add to cart
64
PA08522
Each
$250.00
add to cart
72
44041
Each
$16.48
add to cart
76
44093
Each
$10.00
add to cart
90, 67
51008
Each
$195.00
add to cart
91, 83
60208
Each
$45.00
add to cart
