Consolidated Dutchwest 264CL, 264CCL and 264CCLR
Consolidated Dutchwest Vermont Castings 264CL stove manufactured in 1980-1982 has glass door panels, a side horizontal shaker bar, a slider grate, and a flue collar that bolts onto the top or back of the stove. There is a blockoff plate for the opening not used. It has no catalyst, no bypass gate, no cooktop, and no side door. All parts for this stove are the same as the Consolidated Dutchwest 264CL 1982-1984 stove.
The Consolidated Dutchwest 264CL stove manufactured in 1982 - 1984 does not have a catalyst, or a cooktop. It does have a slider grate with a vertical shaker handle. It has a side load door, glass door panels, two separate 8 inch oval flue outlets, and a boot plate. All parts for this stove are the same as the Consolidated Dutchwest 264CCL 1983-1984 stove.
The Consolidated Dutchwest 264CCL stove manufactured in 1983-1984 has a catalyst, a slider grate with a vertical shaker handle and a simple bypass gate. It has no tertiary air. All parts are the same as the Consolidated Dutchwest 264CCL 1984-1986 stove.
The Consolidated Dutchwest 264CCL stove manufactured in 1984-1986 has a catalyst, a simple bypass system, rocker grates, and a limited number had no grate caps. It has no tertiary air. All parts are the same as the Consolidated Dutchwest 264CCL 1986-1987 stove.
Consolidated Dutchwest 264CCL stove manufactured in 1986-1987 was a production model when Vermont Castings purchased the Consolidated Dutchwest line. All parts are the same as the 1989 production model. This stove had a catalyst, tertiary air, a locking bypass system, rocker grates, and a cooktop.
(Picture above 264CCL)
(Pictured above 264CCLR - R stands for a Right Loader)
Consolidated Dutchwest Model 264CCL and 264CCLR Parts List
Articles
REF#
SKU
Name
Price
Qty
